CX 10
Change unit:
/
|
Engine Power |
115 - 119 kW | 154 - 160 HP |
|
Emission Level |
Stage 3A/Tier 3 - Stage 5/Tier 4f | Stage 3A/Tier 3 - Stage 5/Tier 4f |
|
Retract force |
9.000 daN | 20,233 lbs |
|
Feed force |
6.500 daN | 14,613 lbs |
|
Feed stroke |
4.000 mm | 13' 1" |
|
Rotary max torque |
13.000 Nm | 9,588 lb*ft |
|
Rotary max speed |
290 rpm | 290 rpm |
|
Clamping range |
45 - 365 mm | 1" 3/4 - 1' 2" |
|
Weight range |
9,5 - 11,5 t | 20,944 - 25,353 lbs |
| Safety systems | ||
|---|---|---|
| Safety Protection Cage | ||
| Dust Diverter & Suppression Hood | ||
| Radiocontrol | ||
| Rod handling systems | ||
|---|---|---|
| Pipe Loader Arm | ||
