CX 20
Change unit:
/
|
Engine Power |
168 - 180 kW | 225 - 241 HP |
|
Emission Level |
Stage 3A/Tier 3 Stage 5/Tier 4f |
Stage 3A/Tier 3 Stage 5/Tier 4f |
|
Retract force |
20.000 daN | 44,962 lbs |
|
Feed force |
12.000 daN | 26,977 lbs |
|
Feed stroke |
4.500 - 7.000 mm | 14' 9" - 22' 11" |
|
Rotary max torque |
20.000 Nm | 14,751 lb*ft |
|
Rotary max speed |
210 rpm | 210 rpm |
|
Clamping range |
45 - 365 mm | 1" 3/4 - 1' 2" |
|
Weight range |
17 - 19 t | 37,479 - 41,888 lbs |
| Safety systems | ||
|---|---|---|
| Safety Protection Cage | ||
| Dust Diverter & Suppression Hood | ||
| Radiocontrol | ||
| Rod handling systems | ||
|---|---|---|
| Pipe Loader Arm | ||
