CX 30
Change unit:
/
|
Engine Power |
201 - 209 kW | 269 - 280 HP |
|
Emission Level |
Stage 3A/Tier 3 Stage 5/Tier 4f |
Stage 3A/Tier 3 Stage 5/Tier 4f |
|
Retract force |
30.000 daN | 67,443 lbs |
|
Feed force |
12.000 daN | 26,977 lbs |
|
Feed stroke |
4.500 - 7.000 mm | 14' 9" - 22' 11" |
|
Rotary max torque |
37.500 Nm | 27,659 lb*ft |
|
Rotary max speed |
150 rpm | 150 rpm |
|
Clamping range |
45 - 365 mm | 1" 3/4 - 1' 2" |
|
Weight range |
20 - 23 t | 44,092 - 50,706 lbs |
| Safety systems | ||
|---|---|---|
| Safety Protection Cage | ||
| Dust Diverter & Suppression Hood | ||
| Radiocontrol | ||
| Rod handling system | ||
|---|---|---|
| Pipe Loader Arm | ||
